| Measuring range | 0 to 0.029 mg/L
→ “Tick mark” symbol on the display screen means “No Alcohol Detected”, visually supported by a green LED. From 0.030 mg/L
→ “X” symbol on the display screen means “Alcohol Detected”, visually supported by a red LED. From 2.5 mg/L → Measuring range exceeded (↑↑↑) |
| Standard sampling | Sampling starts automatically when the minimum volume or predefined blowing time is reached. Passive sampling can be done with or without a funnel. Sampling can be triggered manually while the test subject blows into the funnel. |
| Start-up time | Ready to use approx. 4 sec. after switching on |
| Ready for use | Approx. 2 s after powering up |
| Display of test results | After approx. 2 sec. (at 0 to 0.029 mg/L);
after approx. 6 sec. (at e.g. 0.5 mg/L, at room temperature).) |
| Measurement basis | Electrochemical DrägerSensor®, alchohol-specific |
| Display | > Graphic LCD display with backlight
32 x 22 mm (128 x 64 pixel) |
| LEDs | Two-colours, for supporting test results and warning messages on the display |
| Acoustic signals | > Various signal tones for supporting display and warning messages |
| Memory | Stores the latest 500 test results
with test number, date and time |
| Energy supply | 3x AA batteries, charge status shown on display;
with the battery life from 3x AA batteries,
more than 5,000 tests can be performed. |
| Funnel intake | Click adapter for funnel |
| Funnel | Hygienic, individually packaged with air outlets for minimising back-flow of expired air |
| Operating design | Test functions are started with the “OK” button; two arrow buttons are used to navigate through the menu |
| Calibration | Wet- or dry-gas calibration with the Alcotest 5000 calibration adapter |
| Exterior | Impact-proof ABS/PC |
| Impact-proof ABS/PC | Approx. 63 x 219 x 41 mm; approx. 245 g incl. funnel and batteries |
| Vibration and impact resistance | EN 60068-2-27, EN 60068-2-6; EN 60068-2-64 |
| CE marking | EMC Directive |
| Standards | Contactless breath-alcohol testing devices are currently not subject to any standards |
| Internal clock | Warning 30 days before service interval expires |
| Service interva | 24 months |
| Operating temperature | -15 °C to +50 °C |
| Air humidity | 10 to 100 % relative humidity (not condensed and in operation) |
| Ambient pressure | 600 to 1,300 hPa |
